Ghost 2.0 - Bline

Reference: GHOST-B1800-AI

The gHost-B1800 is a professional 4G voice recorder with automatic FTP upload and scheduled recording. It operates fully autonomously via LTE, without the need for Wi-Fi. Featuring a high-sensitivity Knowles microphone, VOX sound detection, and remote SMS control, it provides crystal-clear recordings and discreet monitoring anywhere.

Send via e-mail
Print

Description

4G Voice Recorder gHost-B1800 with FTP Upload and Scheduled Recording is a smart 4G sound recorder designed for remote audio monitoring in places where it is necessary to automatically record sound and securely upload it to an FTP server. Thanks to the integrated 4G LTE module, it operates independently of Wi-Fi networks, ensuring stable data transmission through the LTE network.

This version of the gHost-B adds an advanced recording and upload scheduler, allowing the device to record and transfer data within predefined time windows — without requiring any physical interaction. It is ideal for users who need autonomous and discreet sound monitoring with flexible upload timing.

Key Features:

4G LTE Connection – stable operation without the need for Wi-Fi connection.
Fully Autonomous Operation – records according to selected mode and automatically uploads to the FTP server, where files can be played back anytime.
High-Quality Audio – equipped with a professional Knowles microphone with preamplifier for crystal-clear sound.
High Level of Discretion – can passively record most of the day to a memory card, remaining undetectable to standard RF detectors. Uploads can be scheduled during the night to minimize detection risk.
FTP Upload – use our FTP server or your own. Supports both continuous (UPLMODE1) and scheduled (UPLMODE2) upload modes.
Recording Scheduler – up to 3 time slots for VOX or continuous mode operation.
VOX Noise Detection – with adjustable sensitivity and false trigger filtering.
SMS Remote Control – all parameters (VOX levels, recording duration, schedules, microphone gain, upload windows, etc.) can be configured remotely by SMS commands.
Automatic Callback – the recorder can automatically call you upon noise detection, enabling real-time listening.
Automatic File Naming – each recording is automatically named according to date and time of creation.
Adjustable Microphone Gain – five selectable sensitivity levels.
Long Battery Life – up to 60 hours of recording per single charge (battery capacity 1800 mAh).

Power Consumption and Battery Capacity:

150 mA during active call
250 mA during upload to server
18 mA in standby mode
20 mA in standby mode with VOX
30 mA during recording
Battery capacity: 1800 mAh

Recording to Memory Card:

The gHost-B1800 can passively record to a microSD card and later upload data to an FTP server. Recording can run continuously (RECMODE1) or only upon sound detection (RECMODE2). Each file is timestamped with date and time and can be configured in length via parameter RECDUR. Recording mode and duration can be changed remotely by SMS commands.

Uploading Recordings to FTP Server:

All recordings can be automatically uploaded to an FTP server – either immediately after creation (UPLOADMODE1) or during a scheduled upload window (UPLOADMODE2). This makes the system ideal for secure overnight data transfer.

4G LTE SIM Card Support:

No Wi-Fi connection required – simply insert a SIM card with data and the device will handle uploads through the integrated LTE modem.

Recording Schedules:

You can set up to three daily recording schedules, which may even overlap. For example, you can activate VOX mode from 12:00 to 20:00, while between 14:00 and 14:30 continuous recording will take place.

Example of configuration SMS:
SCHEDREC1#CON1200-08
→ Sets scheduler 1 for continuous recording from 12:00 for 8 hours.

FTP Upload Scheduler:

Uploads can be set to occur immediately (UPLMODE1) or only within a specific time window (UPLMODE2). This allows the device to record throughout the day and upload all files later during a safe time slot, for example at night.

Remote SMS Configuration:

All device parameters can be adjusted remotely via SMS commands, giving you full flexibility to adapt the recorder’s operation to your needs at any time.

Exceptional Sound Quality:

Equipped with a Knowles microphone and preamplifier, the gHost-B1800 provides superb sound clarity — whispers are audible up to 5 meters away, and normal conversations beyond 15 meters. Sound quality of recordings exceeds that of live GSM listening.

Automatic Call or Recording on Noise Detection:

When noise is detected, the device can automatically call a preset number (RECMODE0) or start recording to internal memory (RECMODE2). Sensitivity and operation modes can be modified through SMS commands.

Unlimited Distance Listening:

Wherever there is mobile network coverage, you can listen in real time to what’s happening in your chosen environment. Simply call the number inserted in the device or wait for the device to call you upon noise detection (RECMODE0).

Additional Features:
